# CMake for FreeRTOS ## Prerequisites ### Host OS requirements Generally any version of Windows, macOS and Linux are supported provided the compilation toolchain of the target device is available on that OS. **Note**: Windows subsystem for Linux (WSL) is not supported, please use native CMake on Windows. ### CMake **CMake version 3.13 or higher is required**. You can download the binary distribution from [CMake's official website](https://cmake.org/download/), or install with your OS package manager e.g., homebrew on macOS and [scoop](https://scoop.sh/) or [chocolatey](https://chocolatey.org/) on Windows. Note that the CMake package provided in many Linux distributions' package managers are out of date most of time, you can choose another package manager like [linuxbrew](http://linuxbrew.sh/) or [nix](https://nixos.org/nix/) in this case. If you download the binary distribution, you also need to add the CMake executable to the `PATH` environment variable if you want to use it from command line. ### Native build system CMake can target many native build systems. Generally you can choose either [GNU Make]( https://www.gnu.org/software/make) or [Ninja](https://github.com/ninja-build/ninja/releases). Both of them can be installed via package managers on Linux, macOS and Windows. Ninja is preferred when compiler is supported, it is faster than Make and also natively support all desktop OS. For using Make on Windows, you can install a standalone version from [Equation]( http://www.equation.com/servlet/equation.cmd?fa=make), or install [MinGW]( https://sourceforge.net/projects/mingw-w64/files) which bundles make. **Note**: The Make executable in MinGW is called `mingw32-make.exe` instead of `make.exe`. ## Building instructions Basically there are 2 steps to build any CMake based project, 1. Run CMake to generate build files for a native build system, e.g., Make or Ninja. 1. Invoke the native build system to build the project. By default, CMake targets your host OS. To use it for cross compiling, you need to set `CMAKE_TOOLCHAIN_FILE` before CMake reads your top level `CMakeLists.txt` file (usually from commandline). This "toolchain file" specifies which compiler to use and set some CMake variables like system name and default search path. For more details of cross compiling with CMake, check the [official wiki](https://gitlab.kitware.com/cmake/community/wikis/doc/cmake/CrossCompiling). ### Generate build files To run CMake for FreeRTOS, you need to specify 2 things, 1. Target MCU, e.g., TI's CC3220SF LaunchPad. 1. Compiler to use, e.g., GCC for ARM. Note that you need to make sure it's either in `PATH` environment variable or let CMake know where to find it. CMake comes with a [command-line tool](https://cmake.org/cmake/help/latest/manual/cmake.1.html) and an [interactive GUI tool](https://cmake.org/cmake/help/latest/manual/cmake-gui.1.html). You can use any of them. #### Commandline instructions By default demos are compiled. You can however select test by adding the command '-DAFR_ENABLE_TESTS=1' You can use `VENDOR` and `BOARD` to specify which MCU you are targeting, and `COMPILER` to tell which compiler you want to use. The values of `VENDOR` and `BOARD` must match the folder names under `cmake/vendors`. And the value of `COMPILER` must match the file names under `cmake/toolchains`, `CMAKE_TOOLCHAIN_FILE` will be set to this file. For example, issue the following command from the root directory **(requires TI compiler in `PATH`)**, ```sh # `-S` and `-B` options tell CMake where our source code is and where to # put the generated build files. cmake -DVENDOR=ti -DBOARD=cc3220_launchpad -DCOMPILER=arm-ti -S. -Bbuild # If you're on Windows, also add -G"Unix Makefiles" or -GNinja because # CMake will use Visual Studio as the default generator on Windows. cmake -DVENDOR=ti -DBOARD=cc3220_launchpad -DCOMPILER=arm-ti -S. -Bbuild -GNinja ``` Note that you don't have to use full names for `VENDOR` and `BOARD`, partial names are also OK provided there is only a single match. We use regular expression `${VENDOR}.*` and `${BOARD}.*` to search for a matching board. For example, ```sh cmake -DVENDOR=ti -DCOMPILER=arm-ti -S. -Bbuild cmake -DBOARD=cc3220 -DCOMPILER=arm-ti -S. -Bbuild cmake -DVENDOR=t -DBOARD=cc -DCOMPILER=arm-ti -S. -Bbuild ``` You can also set `CMAKE_TOOLCHAIN_FILE` directly if you want to use a custom file from a different location instead of the default `cmake/toolchains`, for example, ```sh cmake -DBOARD=cc3220 -DCMAKE_TOOLCHAIN_FILE='/path/to/toolchain_file.cmake' -S. -Bbuild ``` Additionally, if the toolchain file does not use absolute path for your compiler, and you didn't add your compiler to the PATH environment variable, CMake may not be able to find it. In this case, you can use `AFR_TOOLCHAIN_PATH` to provide a search path. We will search the directory and its `bin` sub-folder, ```sh cmake -DVENDOR=ti -DBOARD=cc3220 -DCOMPILER=arm-ti \ -DAFR_TOOLCHAIN_PATH=/Applications/ti/ti-cgt-arm_18.1.3.LTS -S. -Bbuild ``` To enable debugging, you need to set `CMAKE_BUILD_TYPE` to `debug`, CMake will then add debug flags to the compile options. This will build FreeRTOS with debug symbols. You can also set `CMAKE_BUILD_TYPE` to `release`, CMake will then add optimization flags to the compile options. ```sh # Build with debug symbols cmake -DBOARD=cc3220 -DCOMPILER=arm-ti -DCMAKE_BUILD_TYPE=debug -S. -Bbuild ``` #### GUI instructions Start `cmake-gui`, specify source code and output binaries locations: CMake main window Click **Configure** and choose **Specify toolchain file for cross-compiling**. Optionally, select a build system from the **Specify the build generator for this project** dropdown list. CMake main window Click next, then choose the toolchain file, e.g. `/cmake/toolchains/arm-ti.cmake`, and click **Finish**. You will see a pop up window that says "Error in configuration process". This is because we default to the template board, which doesn't provide any portable layer target. Now you should see a window that looks like this: CMake main window From the dropdown box of `AFR_BOARD`, select your board and click **Configure** again. Then click the **Generate** button. After it's finished, you should see the generated native build system files in the output binaries directory. ### Build FreeRTOS To build FreeRTOS, simply call the native build system command from the output binaries directory. Note that each FreeRTOS module will be built separately and output a static library. ```sh cd build make -j4 ``` Alternatively, you can let CMake call the native build system for you, ```sh cmake --build ``` CMake provides an abstraction layer for calling native build systems, some common usages are, ```sh # Take advantage of CPU cores. cmake --build --parallel 8 # Build specific targets. cmake --build --target afr_kernel # Clean first, then build. cmake --build --clean-first ``` Check the CMake official document to see more information about the [build tool mode]( https://cmake.org/cmake/help/latest/manual/cmake.1.html#build-tool-mode). ## Porting Guide To add CMake support for a new hardware, see the document [here](doc/porting_guide.md).
