# Contributing to AWS Toolkit for VS Code Thanks for taking the time to help improve the AWS Toolkit! We greatly value feedback and contributions from the community. Reviewing this document will maximize your success in working with the codebase and sending pull requests. ## Getting Started ### Find things to do If you're looking for ideas about where to contribute, consider [_good first issue_](https://github.com/aws/aws-toolkit-vscode/labels/good%20first%20issue) issues. ### Setup To develop this project, install these dependencies: - [Visual Studio Code](https://code.visualstudio.com/Download) - [NodeJS and NPM](https://nodejs.org/) (latest version of both) - [Typescript](https://www.typescriptlang.org/) - [Git](https://git-scm.com/downloads) - (optional) Set `git blame` to ignore noise-commits: `git config blame.ignoreRevsFile .git-blame-ignore-revs` - [AWS `git secrets`](https://github.com/awslabs/git-secrets) - (optional) [AWS SAM CLI](https://docs.aws.amazon.com/serverless-application-model/latest/developerguide/serverless-sam-cli-install.html) - (optional) [Docker](https://docs.docker.com/get-docker/) Then clone the repository and install NPM packages: git clone git@github.com:aws/aws-toolkit-vscode.git cd aws-toolkit-vscode npm install ### Run To run the extension from VSCode as a Node.js app: 1. Select the Run panel from the sidebar. 2. From the dropdown at the top of the Run pane, choose `Extension`. 3. Press `F5` to launch a new instance of VSCode with the extension installed and the debugger attached. To run the extension from VSCode in "web mode" (a browser app, or "PWA"): 1. Select the Run panel from the sidebar. 2. From the dropdown at the top of the Run pane, choose `Extension (web)`. 3. Press `F5` to launch a new instance of VSCode (web mode) with the extension installed and the debugger attached. ### Build When you launch the extension or run tests from VSCode, it will automatically build the extension and watch for changes. You can also use these NPM tasks (see `npm run` for the full list): - To build once: ``` npm run compile ``` - To build and watch for file changes: ``` npm run watch ``` - To build a release artifact (VSIX): ``` npm run package ``` - This uses webpack which may exhaust the default Node heap size on Linux. To fix this set `--max-old-space-size`: ``` export NODE_OPTIONS=--max-old-space-size=8192 ``` - To build a "debug" VSIX artifact (faster and does not minify): ``` npm run package -- --debug ``` ## Develop ### Guidelines - Project patterns and practices: [CODE_GUIDELINES.md](./docs/CODE_GUIDELINES.md) - [VS Code Extension Guidelines](https://code.visualstudio.com/api/references/extension-guidelines) - [VS Code API Documentation](https://code.visualstudio.com/api/references/vscode-api) - [VS Code Extension Capabilities](https://code.visualstudio.com/api/extension-capabilities/common-capabilities) ### Technical notes - VSCode extensions have a [100MB](https://github.com/Microsoft/vscode-vsce/issues/179) file size limit. - `src/testFixtures/` is excluded in `.vscode/settings.json`, to prevent VSCode from treating its files as project files. - The codebase provides [globals](https://github.com/aws/aws-toolkit-vscode/blob/c6ad8ecd602fab64b563519dc2a455ee0b252dde/src/shared/extensionGlobals.ts#L55), which must be used instead of some common javascript globals. In particular, clock-related things like `Date` and `setTimeout` must not be used directly, instead use `globals.clock.Date` and `globals.clock.setTimeout`. [#2343](https://github.com/aws/aws-toolkit-vscode/pull/2343) - VSCode extension examples: - Tests - Use `function ()` and `async function ()` syntax for `describe()` and `it()` callbacks [instead of arrow functions.](https://mochajs.org/#arrow-functions) - Do NOT include any `await` functions in `describe()` blocks directly (usage in `before`, `beforeEach`, `after`, `afterEach`, and `it` blocks is fine). - `await` in `describe()` causes the framework to always evaluate the `describe` block and can cause issues with either tests not running or always running (if other tests are marked with `.only`) - Tests that require a premade value from a Promise should initialize the value as a `let` and make the `await`ed assignment in `before()`. - How to debug unresolved promise rejections: 1. Declare a global unhandledRejection handler. ```ts process.on('unhandledRejection', e => { getLogger('channel').error( localize( 'AWS.channel.aws.toolkit.activation.error', 'Error Activating {0} Toolkit: {1}', getIdeProperties().company, (e as Error).message ) ) if (e !== undefined) { throw e } }) ``` 2. Put a breakpoint on it. 3. Run all tests. ### Test See [TESTPLAN.md](./docs/TESTPLAN.md) to understand the project's test structure, mechanics and philosophy. You can run tests directly from VSCode: 1. Select `View > Debug`, or select the Debug pane from the sidebar. 2. From the dropdown at the top of the Debug pane, select the `Extension Tests` configuration. 3. Press `F5` to run tests with the debugger attached. You can also run tests from the command line: npm run test npm run testInteg Tests will write logs to `./.test-reports/testLog.log`. #### Run a specific test To run a single test in VSCode, do any one of: - Run the _Extension Tests (current file)_ launch-config. - Use Mocha's [it.only()](https://mochajs.org/#exclusive-tests) or `describe.only()`. - Run in your terminal: - Unix/macOS/POSIX shell: ``` TEST_FILE=src/test/foo.test npm run test ``` - Powershell: ``` $Env:TEST_FILE = "src/test/foo.test"; npm run test ``` - To run all tests in a particular subdirectory, you can edit `src/test/index.ts:rootTestsPath` to point to a subdirectory: ``` rootTestsPath: __dirname + '/shared/sam/debugger/' ``` ### Coverage report You can find the coverage report at `./coverage/index.html` after running the tests. Tests ran from the workspace launch config won't generate a coverage report automatically because it can break file watching. A few manual steps are needed instead: - Run the command `Tasks: Run Build Task` if not already active - Instrument built code with `npm run instrument` - Exercise the code (`Extension Tests`, `Integration Tests`, etc.) - Generate a report with `npm run report` ### Prerelease artifacts - CI automatically publishes GitHub [prereleases](https://github.com/aws/aws-toolkit-vscode/releases) for `master` and `feature/x` branches, including `.vsix` artifacts which can be used to test the latest build for that branch. Each prerelease and its artifact are continually updated from the HEAD of its branch. - PR artifacts: each pull request is processed by an AWS CodeBuild job which runs all tests and provides the build result via the _Details_ link as shown below. - CI artifact ### CodeCatalyst Blueprints You can find documentation to create VSCode IDE settings for CodeCatalyst blueprints at [docs/vscode-config.md](./docs/vscode-config.md). ## Pull Requests Before sending a pull request: 1. Check that you are working against the latest source on the `master` branch. 2. Check existing open, and recently merged, pull requests to make sure someone else hasn't addressed the problem already. 3. Open an issue to discuss any significant work. To send a pull request: 1. [Fork the repository](https://help.github.com/articles/fork-a-repo/). 2. Modify the source; focus on the specific change you are contributing. If you also reformat all the code, it will be hard for us to focus on your change. - Read the [project guidelines](#guidelines), this is very important for non-trivial changes. 3. Commit to your fork [using clear commit messages](#commit-messages). 4. Update the changelog by running `npm run newChange`. - Note: the main purpose of the `newChange` task is to avoid merge conflicts. 5. [Create a pull request](https://help.github.com/articles/creating-a-pull-request/). 6. Pay attention to any CI failures reported in the pull request. ### Commit messages Generally your PR description should be a copy-paste of your commit message(s). If your PR description provides insight and context, that also should exist in the commit message. Source control (Git) is our source-of-truth, not GitHub. Follow these [commit message guidelines](https://cbea.ms/git-commit/): - Subject: single line up to 50-72 characters - Imperative voice ("Fix bug", not "Fixed"/"Fixes"/"Fixing"). - Body: for non-trivial or uncommon changes, explain your motivation for the change and contrast your implementation with previous behavior. - Often you can save a _lot_ of words by using this simple template: ``` Problem: … Solution: … ``` A [good commit message](https://git-scm.com/book/en/v2/Distributed-Git-Contributing-to-a-Project) has a short subject line and unlimited detail in the body. [Good explanations](https://nav.al/explanations) are acts of creativity. The "tiny subject line" constraint reminds you to clarify the essence of the commit, and makes the log easy for humans to scan. The commit log is an artifact that will outlive most code. Prefix the subject with `type(topic):` ([conventional commits](https://www.conventionalcommits.org/) format): this again helps humans (and scripts) scan and omit ranges of the history at a glance. ## Tooling Besides the typical develop/test/run cycle describe above, there are some tools for special cases such as build tasks, generating telemetry, generating SDKs, etc. ### Toolkit developer settings (`aws.dev.*`) The [DevSettngs](https://github.com/aws/aws-toolkit-vscode/blob/479b9d45b5f5ad30fc10567e649b59801053aeba/src/shared/settings.ts#L553) class defines various developer-only settings that change the behavior of the Toolkit for testing and development purposes. To use a setting just add it to your `settings.json`. At runtime, if the Toolkit reads any of these settings, the "AWS" statusbar item will [change its color](https://github.com/aws/aws-toolkit-vscode/blob/479b9d45b5f5ad30fc10567e649b59801053aeba/src/credentials/awsCredentialsStatusBarItem.ts#L45). The setting `aws.dev.forceDevMode` will take precedence over all dev settings and enable dev mode on `"aws.dev.forceDevMode": true` or disable on `"aws.dev.forceDevMode": false`. ### Logging The `aws.dev.logfile` setting allows you to set the path of the logfile. This makes it easy to follow and filter the logfile using shell tools like `tail` and `grep`. For example in settings.json, "aws.dev.logfile": "~/awstoolkit.log", then following the log with: tail -F ~/awstoolkit.log ### Service Endpoints Endpoint overrides can be set per-service using the `aws.dev.endpoints` settings. This is a JSON object where each key is the service ID (case-insensitive) and each value is the endpoint. Refer to the SDK [API models](https://github.com/aws/aws-sdk-js/tree/master/apis) to find relevant service IDs. Example: ```json "aws.dev.endpoints": { "s3": "http://example.com" } ``` ### Telemetry and Automation Metrics are only emitted if the extension is assumed to be ran from an actual user rather than automation scripts. This condition is checked through an environment variable `AWS_TOOLKIT_AUTOMATION` which is set by test entry points. If any truthy value is present, telemetry will be dropped if the current build is not a release version. Utility functions, such as `assertTelemetry`, can be used to test specific telemetry emits even in automation. ### SAM/CFN ("goformation") JSON schema See [docs/cfn-schema-support.md](./docs/cfn-schema-support.md) for how to fix and improve the JSON schema that provides auto-completion and syntax checking of SAM and CloudFormation `template.yaml` files. ### AWS SDK generator When the AWS SDK does not (yet) support a service but you have an API model file (`*.api.json`), use `generateServiceClient.ts` to generate a TypeScript `*.d.ts` file and pass that to the AWS JS SDK to create requests just from the model/types. 1. Add an entry to the list in `generateServiceClient.ts`: ```diff diff --git a/src/scripts/build/generateServiceClient.ts b/src/scripts/build/generateServiceClient.ts index 8bb278972d29..6c6914ec8812 100644 --- a/src/scripts/build/generateServiceClient.ts +++ b/src/scripts/build/generateServiceClient.ts @@ -199,6 +199,10 @@ ${fileContents} ;(async () => { const serviceClientDefinitions: ServiceClientDefinition[] = [ + { + serviceJsonPath: 'src/shared/foo.api.json', + serviceName: 'ClientFoo' + }, { serviceJsonPath: 'src/shared/telemetry/service-2.json', serviceName: 'ClientTelemetry', ``` 2. Run the script: ``` npm run generateClients ``` 3. The script produces a `*.d.ts` file (used only for IDE code-completion, not required to actually make requests): ``` src/shared/foo.d.ts ``` 4. To make requests with the SDK, pass the `*.api.json` service model to `globals.sdkClientBuilder.createAndConfigureServiceClient` as a generic `Service` with `apiConfig=require('foo.api.json')`. ```ts // Import the `*.d.ts` file for code-completion convenience. import * as ClientFoo from '../shared/clientfoo' // The AWS JS SDK uses this to dynamically build service requests. import apiConfig = require('../shared/foo.api.json') ... const c = await globals.sdkClientBuilder.createAwsService( opts => new Service(opts), { apiConfig: apiConfig, region: 'us-west-2', credentials: credentials, correctClockSkew: true, endpoint: 'foo-beta.aws.dev', }) as ClientFoo const req = c.getThing({ id: 'asdf' }) req.send(function (err, data) { ... }); ``` ### Webview dev-server Webviews can be hot-reloaded (updated without restarting the extension) by running a developer server provided by webpack. This server is started automatically when running the `Extension` launch configuration. You can also start it by running `npm serve`. Note that only frontend components will be updated; if you change backend code you will still need to restart the development extension. ### Font generation For extensions to contribute their own codicons, VSCode requires a font file as well as how that font maps to codicon IDs. The mapping is found in `package.json` under the `icons` contribution point. Icons located in `resources/icons` are stitched together at build-time into a single font, automatically adding mappings to `package.json`. More information can be found [here](docs/icons.md). As a simple example, let's say I wanted to add a new icon for CloudWatch log streams. I would do the following: 1. Place the icon in `resources/icons/aws/cloudwatch`. I'l name the icon `log-stream.svg`. 1. Use `npm run generatePackage` to update `package.json`. Commit this change with the new icon. 1. You can now use the icon in the Toolkit: ```ts getIcon('aws-cloudwatch-log-stream') ``` ### Beta artifacts The Toolkit codebase contains logic in `src/dev/beta.ts` to support development during private betas. Creating a beta artifact requires a _stable_ URL to source Toolkit builds from. This URL should be added to `src/dev/config.ts`. Subsequent Toolkit artifacts will have their version set to `1.999.0` with a commit hash. Builds will automatically query the URL to check for a new build once a day and on every reload. ### VSCode Marketplace The [marketplace page](https://marketplace.visualstudio.com/itemdetails?itemName=AmazonWebServices.aws-toolkit-vscode) is defined in `README.quickstart.vscode.md` (which replaces `README.md` during the release automation). The `vsce` package tool always [replaces relative image paths](https://github.com/microsoft/vscode-vsce/blob/9478dbd11ea2e7adb23ec72923e889c7bb215263/src/package.ts#L885) with URLs pointing to `HEAD` on GitHub (`https://github.com/aws/aws-toolkit-vscode/raw/HEAD/…/foo.gif`). Note therefore: 1. Don't delete images from `docs/marketplace/` unless the _current published_ AWS Toolkit release doesn't depend on them. 2. `HEAD` implies that the URL depends on the current _default branch_ (i.e. `master`). Changes to other branches won't affect the marketplace page. ## Importing icons from other open source repos If you are contribuing visual assets from other open source repos, the source repo must have a compatible license (such as MIT), and we need to document the source of the images. Follow these steps: 1. Use a separate location in this repo for every repo/organization where images are sourced from. See `resources/icons/vscode` as an example. 1. Copy the source repo's licence into this destination location's LICENSE.txt file 1. Create a README.md in the destination location, and type in a copyright attribution: ```text The AWS Toolkit for VS Code includes the following third-party software/licensing: Icons contained in this folder and subfolders are from : ``` 1. Add an entry [here](docs/icons.md#third-party) summarizing the new destination location, where the assets were sourced from, and a brief rationale. [PR #227](https://github.com/aws/aws-toolkit-vscode/pull/227) shows an example. ## Code of Conduct This project has adopted the [Amazon Open Source Code of Conduct](https://aws.github.io/code-of-conduct). For more information see the [Code of Conduct FAQ](https://aws.github.io/code-of-conduct-faq) or contact opensource-codeofconduct@amazon.com with any additional questions or comments. ## Security issues If you discover a potential security issue in this project we ask that you notify AWS/Amazon Security via the [vulnerability reporting page](http://aws.amazon.com/security/vulnerability-reporting/). Please do **not** create a public issue. ## Licensing See the [LICENSE](https://github.com/aws/aws-vscode-toolkit/blob/master/LICENSE) file for our project's licensing. We will ask you to confirm the licensing of your contribution. We may ask you to sign a [Contributor License Agreement (CLA)](http://en.wikipedia.org/wiki/Contributor_License_Agreement) for larger changes.
